| Model | MGTL-22/40 | ||
| Applicable material | General-purpose plastics, engineering resins, etc. | ||
| Screw diameter | 21.7mm | ||
| L/D | 40 | ||
| Screw speed | 0-600rpm | ||
| Pressure measurement range | 0-50MPa | ||
| Pressure measurement accuracy | 0.5%FS | ||
| Operating temperature | Rt-350℃ | ||
| Temperature accuracy | ±1℃ | ||
| Number of pull strips | 4 pieces | ||
| Pellet length | 3±0.2mm | ||
| Pelletizing diameter | 1-4mm | ||
| Cutter speed | 0-800rpm | ||
| Working voltage | 3φ380VAC±10%，1φ220VAC±10%，50Hz | ||
| Rated power | About 25kW | ||
| L×W×H | 4800mm×950mm×1800mm | ||
| Weight | About 1300kg |
